| Nominal Pressure | 10000KN |
| hot press platen size | 4200(L)*1370(W)*60mm(H) |
| Feeding mode | double input and double output |
| Plywood size(mm) | 12703000mm,12703650mm,12703950mm,12701830mm,970*1830mm |
| Max. opening space | 80mm |
| Number of layers | 25 layers |
| Main oil cylinder of press | Φ2602150mm8PCS |
| Working stroke(mm) | 2000mm |
| Working press(kg/cm2) | 17kg/cm2 |
| Closing speed(M/min) | 15M/min |
| Overall size(mm) | 5030mm(L)*1370mm(W)*7200mm(H) |
| Nitrogen tank size | 1440mm*6620mm(9CBM) 1PC |
| Weight of Nitrogen tank | 4900kgs |
| Hydraulic station size | 3200mm(L)*1500mm(W)*2800mm(H) |
| Tank Volume | 7CBM |
| Total weight of hydraulic station | 5800KGS |
| Low pressure pump motor | 22KW*2PCS |
| High pressure pump motor | 5.6KW*1PC |
| Elevator motor | 2.2KW*1PC |
| Total power | 51.8KW |
| Depth of foundation | 3000mm |
| Total weight | 120T |
| Hydraulic station | Fully sealed dust-free design |
| Total weight | 90T |
