Working width: 40–1300 mm
Working thickness: 3–80 mm
Working length: ≥750 mm
Sanding belt speed: 24 m/s
Feeding speed: 5–40 m/min
Sanding belt size: 1340 × 2800 mm
Diameter of contact rollers: 400 mm steel roller, 400 mm rubber roller
Total motor power: 142.5 kW
Main motor power: 75 kW, 55 kW
Feeding motor power: 11 kW
Lifting motor power: 0.75 kW
Brushing motor power: 0.75 kW
Voltage requirement: 380 V, 50 Hz, 3 Phase
Working air pressure: 0.55 MPa
Compressed air consumption: 0.12 m³/min
Suction speed: 25–30 m/s
Volume of suction: 23,000 m³/h
Overall dimension: 3300 × 3000 × 2450 mm
Net weight: 11,000 kg
Sanding roller bearing: NSK
Bearing with seat: FSB
Pneumatic components: AirTAC
Photoelectric switch: OMRON
Limit switch: CHINT
Main motor: Huali
Reducer: DONLY
PLC: DELTA
Frequency converter: SHIHLIN
AC circuit breakers and contactors: CHINT
Steel roller processing: Shaft head forging, High frequency quenching
Rubber roller processing: Wear-resistant rubber roller
Bearing box: Ductile iron
