| Nominal Pressure | 8000KN |
| hot press platen size | 2700(L)*1370(W)*42mm(H) |
| Feeding mode | double input and double output |
| Plywood size(mm) | 1220*2440mm |
| Max. opening space | 70mm |
| Number of layers | 40 layers |
| Main oil cylinder of press | Φ3202950mm4PCS(Main) |
| Working stroke(mm) | 2800mm |
| Working press(kg/cm2) | 21kg/cm2 |
| Closing speed(M/min) | 15M/min |
| Overall size(mm) | 3590mm(L)*1370mm(W)*7700mm(H) |
| Nitrogen tank size | 1440mm*6620mm(9CBM) 1PC |
| Weight of Nitrogen tank | 4900kgs |
| Hydraulic station size | 3200(L)*1500(W)*2800(H)mm |
| Tank Volume | 7CBM |
| Total weight of hydraulic station | 5800KGS |
| Low pressure pump motor | 22KW*2PCS |
| High pressure pump motor | 5.6KW*1PC |
| Elevator motor | 2.2KW*1PC |
| Total power | 51.8KW |
| Height | 7500mm |
| Depth of foundation | 5750mm |
| Total weight | 98T |
