Number of Hot Plates: 12
Format Size (mm): 1370 × 2700 × 52
Number of Piston Cylinders: 6
Nominal Pressure (T): 100T
Direction of Boards Into: Transverse
Layer Spacing (mm): 130
Working Stroke (mm): 1450
Withstand Voltage (MPa): ≤25
No-loading Closing Time (s): 15
Low-pressure Pump Flow (L/min): 87
Allowable Pressure (MPa): ≤3
Power (kW): 22
High-pressure Pump Flow (L/min): 25
Allowable Pressure (MPa): ≤25
Power (kW): 11
Overall Dimensions (mm): 1370 × 3700 × 4600
Control Methods: Full automatic
Electric Appliance: Schneider
Pressure Gauge: Wuxi
Hydraulic Valve: Jinan
Framework Form: Gantry Framework
Upper and Lower Beam Thickness (mm): 900 × 900
Plate Thickness of Main Part Framework (mm): 40 × 4
Top Plate Thickness (mm): 30
Column Width (mm): 400
