Peeling Thickness: 0.5 – 2.6 mm
Maximum Peeling Diameter: 550 mm
Minimum Core Diameter: 35 mm
Peeling Speed: 0 – 80 m/min
Total Weight: 10.5 T
Specifications
Double Roller Diameter: 125 mm, K87 hard-tooth gearbox, 11 kW motor × 2
Single Roller Diameter: 100 mm R87 hard-tooth gearbox, 11 kW motor × 2
Feeding System: K87 hard-tooth gearbox, 15 kW motor × 1
Chopping Knife: RV110 gearbox, 3.7 kW motor × 1
Rubber Roller: RV110 gearbox, 4 kW motor × 1
Guiding System: Oil-immersed slide rail & Ø95 mm lead screw, 1 set each
Knife Gap Adjustment Linear Rails: 2 rails, 55# steel
Hydraulic Knife Clamping + Knife Box: 2.2 kW
CNC Knife Gap Adjustment: 2.2 kW, synchronized
