Peeling Thickness: 0.3 – 1.6 mm
Maximum Peeling Diameter: 550 mm
Minimum Core Diameter: 35 mm
Peeling Speed: 0 – 80 m/min
Total Weight: 10T
Specifications
Double Roller Diameter: 125 mm, R87 hard-tooth gearbox, 15 kW Zhongtai motor × 1
Single Roller Diameter: 100 mm, R87 hard-tooth gearbox, 11 kW Zhongtai motor × 2
Feeding System: R87 hard-tooth gearbox, 15 kW motor × 1
Chopping Knife: RV130 gearbox, 4 kW motor × 1
Rubber Roller: RV130 gearbox, 4 kW motor (Zhongtai) × 1
Guiding System: Linear rails & Ø95 mm lead screw, 1 set each
Knife Gap Adjustment Linear Rails: 2 rails, 55# steel
Control Box: Inverter (Kewo)
Hydraulic Knife Clamping: 2.2 kW
Knife Box Press: 2 sets
Knife Box Suspension Arm: 1 unit
Peeling Thickness: 0.3 – 1.6 mm
Maximum Peeling Diameter: 550 mm
Minimum Core Diameter: 35 mm
Peeling Speed: 0 – 80 m/min
Total Weight: 10T
