Peeling Thickness: 1.0 – 4.0 mm
Maximum Peeling Diameter: 550 mm
Minimum Core Diameter: 32 mm
Peeling Speed: 0 – 80 m/min
Total Weight: 9T
Specifications
Double Roller Diameter: 125 mm, R87 hard-tooth gearbox, 11 kW motor × 1
Single Roller Diameter: 125 mm, R87 hard-tooth gearbox, 7.5 kW motor × 2
Feeding System: R87 hard-tooth gearbox, 11 kW motor × 1
Chopping Knife: RV120 gearbox, 4 kW motor × 1
Rubber Roller: RV120 gearbox, 4 kW motor × 1
Guiding System: Linear rails, 1 set each
Knife Gap Adjustment Linear Rails: 2 rails, 55# steel
Hydraulic Knife Clamping: 2.2 kW hydraulic station
