Plywood Cold Press Machine

What is Plywood Pre-Pressing?

Before the plywood boards go into the hot press, they are first pressed in a cold press at room temperature. This step uses light pressure to help the glue stick the veneer layers together. It shapes and holds the board in place, making the final hot pressing more effective and improving the overall quality.

Technical Specifications

1.Steel Plate Thickness：

• Frame Plates:35mm
  Leg Width: 370mm*4PCS

2.Hydraulic System：Pollution-free standard hydraulic station
①Taiwan Jiugang hydraulic valves
② SCY10 plunger pump
③ Pump Origin: Shanghai
low-pressure pump
④ Quick Pump: 1 unit

3.Main Hydraulic Cylinder：

① Size: 360×900mm
② Origin: Wuxi
③ Material: Cast steel body, alloy plunger, solid cold-processed, wear-resistant
④ Quantity: 2 units
⑤ Rated Working Pressure: 26 MPa

4.Motors

① High Pressure Pump Motor: 5.5KW × 1 unit
② Low Pressure Pump Motor: 7.5KW × 1 unit

5.Control System

① Control Mode: Fully Automatic
② Electrical Components: Schneider (France)

Why Plywood need Pre-Pressing?

the pre-pressing process helps improve the quality of the final plywood. It shortens the hot pressing time and increases the efficiency of the hot press. Pre-pressed boards are easier to move and handle, making it possible to use machines instead of manual labor, which reduces workers’ physical effort. It also allows for smaller gaps between hot press plates and simpler transport systems, helping save energy and reduce production costs.
